Optoma ZU707T WUXGA Professional Laser Projector
Less bright7,000 lm−1,000 lm
WUXGA7000 lm0.8-301.8"
£3,153.29inc. VAT
In stock
UK stockHome / Installation & Large-Venue Projectors / ViewSonic LSC801WU 8,000 ANSI Lumens WUXGA 3LCD Laser Installation Projector
ViewSonic
ViewSonic LSC801WU 8,000 ANSI Lumens WUXGA 3LCD Laser Installation Projector
£3,059.75inc. VAT
£2,549.79 ex. VAT
In stock, dispatched within 2 working days
1
- Visa
- Mastercard
- American Express
- PayPal
Seen it cheaper? We price-match genuine like-for-like quotes. How it works
Bought in the UK, backed in the UKWhy it matters →
- In UK stock, ships from the UK
- UK manufacturer warranty
- UK-based engineers
- No import duty or customs charges
- GBP pricing, UK VAT invoices
Key specifications
Brightness8,000 ANSI Lumens
Center Lumens8,500
Native Resolution1920x1200 (WUXGA)
Contrast Ratio3,000,000:1
Projection Technology3LCD (3x0.64" with MLA)
Light Source2nd Generation Laser Phosphor
Light Source Life (Normal)20,000 hours
Light Source Life (Eco)30,000 hours
Description
The LSC801WU is ViewSonic's highest-brightness WUXGA 3LCD installation projector in this range, combining a 3x0.64" 3LCD imaging system with 2nd generation laser phosphor light source to deliver 8,000 ANSI lumens and a 3,000,000:1 contrast ratio at native 1920x1200 resolution, projecting up to 300".
A 21:9 aspect ratio mode is optimised for Microsoft Teams Rooms, and a 1.6x optical zoom with horizontal/vertical lens shift and ±25°/±30° keystone correction give installers wide flexibility across boardrooms, lecture halls, galleries and large public venues, all backed by 360-degree projection.
Connectivity includes dual HDMI, a computer input, HDBaseT, RJ45 LAN and RS232, and the projector is certified for Crestron and Q-SYS with compatibility for AMX, PJ Link, ATEN and Extron systems. A light source rated for up to 30,000 hours keeps maintenance and running costs low in always-on commercial deployments.
Key features
8,000 ANSI Lumens, 3LCD
ViewSonic's brightest WUXGA installation model in this series.
21:9 Microsoft Teams Rooms Mode
Aspect ratio optimised for modern collaboration spaces.
H/V Lens Shift & 1.6x Zoom
Flexible installation across large boardrooms and venues.
Crestron & Q-SYS Certified
Also compatible with AMX, PJ Link, ATEN and Extron.
Technical specifications
Choose a section to view its specifications.
Display (5)
- Brightness
- 8,000 ANSI Lumens
- Native Resolution
- 1920x1200 (WUXGA)
- Contrast Ratio
- 3,000,000:1
- Resolution
- 1920x1200 (WUXGA)
- Display Colours
- 1.07 Billion Colours
Connectivity (3)
- Optical Zoom
- 1.6x
- Connectivity
- 2x HDMI, Computer input, HDBaseT, RJ45 LAN, RS232, USB-A, audio in/out
- Input Lag
- 60ms
Audio (1)
- Audio
- 16W speaker, 3.5mm audio out
Power & Physical (4)
- Image Size
- 30"-300"
- Weight
- 7.9 kg
- Dimensions
- 405 x 358 x 137 mm
- Power Consumption
- 385W (normal)
Certifications & Warranty (2)
- Control Certification
- Crestron, Q-SYS, AMX, PJ Link, ATEN, Extron
- Warranty
- 3 years
General (10)
- Center Lumens
- 8,500
- Projection Technology
- 3LCD (3x0.64" with MLA)
- Light Source
- 2nd Generation Laser Phosphor
- Light Source Life (Normal)
- 20,000 hours
- Light Source Life (Eco)
- 30,000 hours
- Throw Ratio
- 1.2-2.0:1
- Keystone Correction
- H ±25°, V ±30°
- Projection Distance
- 0.78 - 12.99 m
- Noise Level
- 37dB (normal) / 27dB (eco)
- Lens Shift
- V: +60%/0%, H: ±29%
Throw distance guide
With its 1.2 to 2:1 throw ratio, here's how far the projector needs to sit from the screen for common 16:10 image sizes. Try our throw distance calculator for your exact room.
Supported image: 30″ to 300″ diagonalLens distance: 0.78 to 12.99 m
Try a size
100"
16:10 diagonal image
2.15 m × 1.35 m
Lens position
2.6 m to 4.3 m
Side view: drag the projector to try its available lens positions
Position fits
Manufacturer lens-distance limit: 0.8 m to 13 m. The dotted lines show the usable zoom positions for this picture size.
| Image size | Image dimensions | Lens distance range |
|---|---|---|
| 40" | 0.86 m × 0.54 m | 1.0 m to 1.7 m |
| 60" | 1.29 m × 0.81 m | 1.6 m to 2.6 m |
| 80" | 1.72 m × 1.08 m | 2.1 m to 3.4 m |
| 100" | 2.15 m × 1.35 m | 2.6 m to 4.3 m |
| 120" | 2.58 m × 1.62 m | 3.1 m to 5.2 m |
| 150" | 3.23 m × 2.02 m | 3.9 m to 6.5 m |
| 200" | 4.31 m × 2.69 m | 5.2 m to 8.6 m |
| 250" | 5.38 m × 3.37 m | 6.5 m to 11 m |
| 300" | 6.46 m × 4.04 m | 7.8 m to 13 m |
Planning from a real wall? Use the projector screen size calculator to upload a photo, preview the image to scale and find projectors that fit within your maximum available space. Replacing an existing projector? The projector replacement calculator checks whether this lens covers the ratio your current mount needs.
Distances are lens-to-screen, calculated from the manufacturer's stated throw ratio; allow for lens shift and mounting hardware. Always confirm against the manufacturer's installation guide before fixing mounts.
See it on your wall, to scale
Choose a picture size, then upload a wall photo, or scan the QR code and take it on your phone. We'll show the projected picture at its real size.
Picture size
100" 16:10 · 2.15 m × 1.35 m
On a computer, the QR code sends your phone photo straight back to this page.
Loading the wall preview…
Complete your setup
Optional extras that fit this product. Tick anything you need and it joins the same basket — or add this product on its own from the buy box above.
Choose a Mount
Choose a Screen
Video Conferencing
No video conferencing options found in our catalogue.
Professional Installation
Want it installed by our AV experts? We offer professional on-site installation including mounting, cable management, and system configuration.
Your Configuration
ViewSonic LSC801WU 8,000 ANSI Lumens WUXGA 3LCD Laser Installation Projector × 1£3,059.75
Total£3,059.75
inc. VAT
1
Frequently asked questions
How bright is the LSC801WU and what resolution does it use?
It delivers 8,000 ANSI lumens (8,500 lm at centre) at native WUXGA resolution, with a 3,000,000:1 contrast ratio from a 3LCD imaging system.
How far from the screen does the LSC801WU need to be?
Its throw ratio is 1.2-2.0:1 with 1.6x optical zoom, putting it roughly 2.6-4.3m from the screen for a 100" 16:10 image, scaling up to a 300" projected image overall.
How long does the laser light source last?
20,000 hours in normal mode, extending to 30,000 hours in eco mode.
What control systems does the LSC801WU support?
It's certified for Crestron and Q-SYS, and is also compatible with AMX, PJ Link, ATEN and Extron systems.
Is the LSC801WU suited to Microsoft Teams Rooms?
Yes, a dedicated 21:9 aspect ratio mode is optimised for Microsoft Teams Rooms.
What warranty comes with the LSC801WU?
It's backed by a 3-year warranty, and it's in stock at TopAV for dispatch within 2 working days.
