Home / 20 - 31" Touch Screens / iiyama T2254MSC-B2AG 21.5" Touch Monitor
iiyama

iiyama T2254MSC-B2AG 21.5" Touch Monitor

£227.81inc. VAT
£189.84 ex. VAT
Low stock (5 left), order soon
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £75.94 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • In UK stock, ships from the UK
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
3 Year Warranty
Installation services available
Key specifications
DesignThin bezel
Diagonal21.5", 54.6cm
PanelIPS LED, AG surface finish
Native resolution1920 x 1080 @100Hz (2.1 megapixel Full HD)
Aspect ratio16:9
Panel brightness300 cd/m²
Static contrast1300:1 with touch
Response time (GTG)4ms
All 63 specifications
Talk to an Expert

Description

ProLite T2254MSC-B2AG 21.5” Optical Bonded PCAP 10pt touchscreen monitor featuring IPS panel technology, Anti Glare coating, active stylus support (MPP 2.0) and edge-to-edge glass Immersive interaction and elegant design - Discover the ProLite T2254MSC-B2AG, a vibrant 21.5" Full HD touchscreen monitor designed for exceptional interactive experiences. Featuring intuitive 10-point touch technology (Optical Bonded PCAP), which ensures smooth and precise touch response and low light reflection. In addition, the display is protected from moisture and potential condensation development. With built-in MPP2.0 support (Microsoft Pen Protocol), a stylus with tilt and pressure sensitivity can be used, providing a natural, precise and intuitive writing or drawing experience, just like a pen on paper. The vibrant colors of the IPS panel will captivate users with precise and natural interaction from a

Also in this range:21.5" T2252MSC-B2AG 23.8" model 24" model 27" model Full specifications Datasheet Compare alternatives

Technical specifications

DesignThin bezel
Diagonal21.5", 54.6cm
PanelIPS LED, AG surface finish
Native resolution1920 x 1080 @100Hz (2.1 megapixel Full HD)
Aspect ratio16:9
Panel brightness300 cd/m²
Static contrast1300:1 with touch
Response time (GTG)4ms
Viewing zonehorizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support16.7mln 8bit
Horizontal Sync30 - 120kHz
Viewable area W x H476 x 268mm, 18.7 x 10.5"
Pixel pitch0.082mm
Bezel colour and finishblack, matte
Touch technologyoptical bonding PCAP
Touch points10 (HID, only with supported OS)
Touch accuracy+- 2mm
Touch methodfinger, glove (latex), capacitive stylus
Touch interfaceUSB
Supported operating systemsAll iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Palm rejectionyes
Digital signal inputHDMI x1DisplayPort x1
Audio outputMini jack x1Speakers 2 x 2W
HDCPyes
USB HUBx2 (v.3.2 (Gen 1, 5Gbit))
ExtraOptical Bonding PCAP, anti-glare coating, MPP2.0 support, TCO10 & EPEAT Silver certification
Kiosk modeyes
Glass hardness7H
OSD key lockyes
OSD languagesEN, DE, FR, ES, IT, PT, RU, JP, NL, PL
Control buttonsJoystick / power button - power/menu, up/input select, down, left/eco/i-Syle color/blue light reducer, right/volume
User controlsPicture adjust (brightness, contrast, eco, adv. contrast, Overdrive, X-Res technology,, black tuner), color settings (6-axis, i-Style color, blue light reducer, gamma, RGB range), color temperature), OSD (horizontal position, vertical position, rotate, time, background, DDC/CI control, display information), language, miscellaneous (sharpness. video mode adjust, opening logo, power led, usb charge), input select, audio settings (volume, mute audio), recall
Blue light reduceryes
Flicker freeyes
Plug&PlayDDC2B
Orientationlandscape, face-up
Height adjustment112mm
Tilt angle90° up; 5° down
VESA mounting100 x 100mm
Cable management systemyes
MTBF50000 hours (excluding backlight)
Cablespower, USB, HDMI
Guidesquick start guide, safety guide
OtherScrewdriver
Cable coveryes
Power supply unitinternal
Power supplyAC 100 - 240V, 50/60Hz
Power usage15W typical, 0.5W stand by, 0.3W off mode
RegulationsCE, EAC, RoHS support, ErP, WEEE, EPEAT, REACH, UKCA
Energy efficiency class (Regulation (EU) 2017/1369)D
EPEAT SilverEPEAT is a comprehensive environmental rating that helps identify greener computers and other electronic equipment. The Silver certification means the monitor meets all required criteria plus at least 50% of the optional requirements. EPEAT Silver is valid in countries where iiyama registers the product. Please visit www.epeat.net for the registration status in your country.
REACH SVHCabove 0.1%: Lead
Product dimensions W x H x D489 x 355 x 241mm
Box dimensions W x H x D570 x 367 x 151mm
Weight (without box)4.9kg
Weight (with box)7.6kg
EAN code4948570125715
User manualT2254MSC-B2AG-usermanual-e.pdf
Technical specificationProLite T2254MSC-B2AG - gb_en.pdf
DrawingT2254MSC-B2_W2_AG drawing.pdf
EU Energy LabelT2254MSC-B2AG EU Energy Label (2295293).pdf
UK Energy LabelT2254MSC-B2AG UK Energy Label (2295293).pdf
Disassembly ManualDisassembly Manual- T2254MSC-B2AG.pdf
