Home / Extenders / Kramer WP-2UT/R-KIT/US-D(W) USB 2.0 PoC Wall-Plate Extender Kit over Extended-Reach CAT
Kramer

Kramer WP-2UT/R-KIT/US-D(W) USB 2.0 PoC Wall-Plate Extender Kit over Extended-Reach CAT

£459.60inc. VAT
£383.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £153.20 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - 1 CATOn an RJ-45 female connector for extension line (PT-2UR)
Outputs - 1 CATOn an RJ-45 female connector for extension line (WP-2UT)
Ports - 1 USBOn a USB-B female connector for USB host extension (WP-2UT)
Ports - 4 USBOn USB-A female connectors for USB devices extension (PT-2UR)
Ports - 1 RS-232On a 3-pin terminal block connector for serial link extension
USB Features - Integrated USB HubsRx: 1wp-2ut
Extended USB - Data RateUp to 480Mbps
Extended USB - Transmitted Data BandwidthUp to 300Mbps
All 22 specifications

Description

WP-2UT/R-KIT is a comprehensive, extended-reach CAT extender kit for USB 2.0, RS-232 and 2-way powering over twisted pair. WP-2UT/R-KIT includes a wall-plate transmitter and compact, mountable receiver. The WP-2UT wall-plate transmitter converts the USB input signal into a CAT signal. The PT-2UR receiver converts the transmitted CAT signal into a USB signal. Kramer publishes this model as a single product page; the exact variant code on this order line is not separately listed by the manufacturer. Manufacturer part number WP-2UT/R-KIT/US-D(W).

Full specifications Datasheet Compare alternatives

Key features

Comprehensive USB Extender - Plug & play USB extender kit for

Comprehensive USB Extender - Plug & play USB extender kit for providing extended-reach CAT signals and 2-way power over twisted pair copper infrastructures. A local USB host is auto-connected to remote-connected USB devices employing either interrupt, bulk or isochronous USB 2.0 standard data transfer communication.

Flexible USB Connectivity - Wide Variety of USB peripheral devices

Flexible USB Connectivity - Wide Variety of USB peripheral devices can be extended including cameras, touch screens, smart boards, hard drives, game controllers, audio devices, printers, scanners, or HID (Human Interface Devices) devices such as a mouse or keyboard. Dual role and OTG (On The Go ) devices such as smart phones and tablets, connected either to a transmitter-side USB host port or receiver-side USB device port, can communication with a remote host or peripheral pairing device.

Remote USB Charging - Fast USB charging of peripheral devices when

Remote USB Charging - Fast USB charging of peripheral devices when the receiver is powered by a power supply, and standard USB charging when the receiver is powered by the transmitter via CAT.

Bidirectional RS-232 Extension - Serial interface data flows in both

Bidirectional RS-232 Extension - Serial interface data flows in both directions, allowing data transmission and device control.

Cost-Effective Maintenance - Status LED indicators facilitate easy

Cost-Effective Maintenance - Status LED indicators facilitate easy local maintenance and troubleshooting.

Easy Installation - Single twisted-pair cable for signal and power

Easy Installation - Single twisted-pair cable for signal and power wiring, the extender kit installation is fast and cost-effective. Transmitter compactly fits into standard US 1-gang in-wall box size, or podium and in-table mounting accessories. Receiver is a compact PicoTOOLS® fan-less enclosure for easy device-adjacent mounting, or side-by-side mounting of 4 units in a 1U rack space with the recommended rack adapter. Compact and flexibly mountable extender kit supports simple decorative integration with room design.

Technical specifications

Connectivity
Inputs - 1 CATOn an RJ-45 female connector for extension line (PT-2UR)
Outputs - 1 CATOn an RJ-45 female connector for extension line (WP-2UT)
Ports - 1 USBOn a USB-B female connector for USB host extension (WP-2UT)
Ports - 4 USBOn USB-A female connectors for USB devices extension (PT-2UR)
Ports - 1 RS-232On a 3-pin terminal block connector for serial link extension
USB Features - Integrated USB HubsRx: 1wp-2ut
Extended USB - Data RateUp to 480Mbps
Extended USB - Transmitted Data BandwidthUp to 300Mbps
Extended USB - Standards ComplianceUSB 1.1 and 2.0
PT-2UR USB CHARGINGMax Total Current When PSU-Powered:2.5A
Power & Physical
Enclosure - Transmitter Size1-gang US
Enclosure - Receiver SizePicoTools®
General
Extension Line - Reach Using Shielded UNIKAT CablesUp to 100m (330ft)
Extension Line - Reach Using CAT 5e CablesUp to 30m (100ft)
Extension Line - Baud Rate9600
User Interface - IndicatorsLINK and ON LEDs
Power - Source12V DC, 2A
Power - WP-2UT Consumption1.1A
Power - PT-2UR Consumption1.85A
Enclosure - TypeAluminum
Enclosure - CoolingConvection ventilation
Accessories - Included1 12V power-supply, 1 C-USB/AB-6 USB type-A male to USB type-B male 2m cable, US 1-gang, white wall-plate frame and faceplate, 1 bracket set

Documents

Kramer WP-2UT/R-KIT/US-D(W) USB 2.0 PoC Wall-Plate Extender Kit over Extended-Reach CAT — manufacturer spec sheet
Kramer WP-2UT/R-KIT/US-D(W) USB 2.0 PoC Wall-Plate Extender Kit over Extended-Reach CAT — manufacturer manual
